Easyarm manipulator is a double or triple articulated arm system that allows to move / rotate parts of various types, shapes and materials
Sistema a doppio braccio articolato
| Code | Easyarm manipulator with | Pressure | GRIPPING CAPACITY ON STEEL FLAT PIECE | GRIPPING CAPACITY ON STEEL ROUND PIECE | PLASTIC/GLASS/BOX ALUMINUM/STAINLESS STEEL/ETC | WORKING AREA MIN-MAX | LIFTING WEIGHT |
|---|---|---|---|---|---|---|---|
| bar | kg | kg | kg | mm | kg | ||
| EAM2-00 | Only Head | 6-8 | / | / | / | 100-1942 | 1-30 |
| EAM2-01 | VACUUM | 6-8 | 1-30 | NO | 1-30 | 100-1942 | 1-28 |
| EAM2-02 | pneu. magnet | 5-8 | 1-46 | 1-30 | NO | 100-1942 | 1-28 |
| EAM2-012 | magnet + vacuum | 5-8 / 6-8 | 1-46 | 1-30 | 1-25 | 100-1942 | 1-28 |
Sistema a triplo braccio articolato
| Code | Easyarm manipulator with | Pressure | GRIPPING CAPACITY ON STEEL FLAT PIECE | GRIPPING CAPACITY ON STEEL ROUND PIECE | PLASTIC/GLASS/BOX ALUMINUM/STAINLESS STEEL/ETC | WORKING AREA MIN-MAX | LIFTING WEIGHT |
|---|---|---|---|---|---|---|---|
| bar | kg | kg | kg | mm | kg | ||
| EAM3-00 | Only Head | 6-8 | / | / | / | 200-2160 | 1-15 |
| EAM3-01 | VACUUM | 6-8 | 1-25 | NO | 1-23 | 200-2160 | 1-15 |
| EAM3-02 | pneu. magnet | 5-8 | 1-46 | 1-30 | NO | 200-2160 | 1-14 |
| EAM3-012 | magnet + vacuum | 5-8 / 6-8 | 1-46 | 1-30 | 1-23 | 200-2160 | 1-14 / 1-15 |
Working Area EAM02
Working Area EAM03
with 4 wheels, 2 with brake, lifting column h=2000mm.
Controllable with electric or pneumatic screwdriver.
Weight: 220 Kg
Column with adjustable height 650mm-1050 mm.
4 turning wheels,
2 with brakes.
Weight: 185 Kg (408 lb).
Controllable with electric or pneumatic screwdriver.
Weight 60 kg
Length from 2000 to 4000 mm with manual movement (motorized optional)
